BEV fireplace for outdoor and indoor

Freestanding BEV fireplace

Luxurious casing options

Porto

FREESTANDING BEV FIREPLACE

The very first BEV fireplace for outdoor usage. An alternative for gas fireplaces used in gardens, patios, hotels, or restaurants. Unconventional casing options from Cosentino – Daze, Laurent & Kreta add a luxurious touch to the surroundings.

  • Real fire without chimney
  • No cleaning
  • No smoke and smell
  • remote control
from
15.350,00
includes VAT
Lead time 15 days
Delivered on a pallet
TECHNICAL SPECIFICATION
Fuel tank capacity
5 L
Maximum burn time
14 h
Flame height regulation
6 stages
Fuel type
Bioethanol 95-96,6%
Flue
Not required
Power supply
230 V
Finish
Black paint coating
Materials
Dekton Daze / Laurent / Kreta , black powder coating
Application
For outdoor and indoor use
Dimmension (Length/Height/Depth)
400/1147/400 mm

Three different facing options

Daze
Laurent
Kreta

CHOOSE YOUR PORTO FINISHING

product
prices from
(includes VAT)
Porto Kreta 15.350,00
Porto Daze 18.302,00
Porto Laurent 18.302,00
product
Porto Kreta
prices from
(includes VAT)
15.350,00
product
Porto Daze
prices from
(includes VAT)
18.302,00
product
Porto Laurent
prices from
(includes VAT)
18.302,00

BEV TECHNOLOGY

Planika puts safety to the highest standards. Our BEV (Burning Ethanol Vapours) Technology ensures no direct contact between the liquid fuel and the flame and complete control over the fire. The entire process is controlled by a microprocessor and numerous safety sensors. This gives you full control over the real fire in your indoor space.

AUTOMATIC BEV FIREPLACE FOR OUTDOORS

Porto BEV fireplace was designed to withstand a variety of weather conditions. Its electronic systems are protected in a sealed, waterproof casing. The high glass shields guard the flame from strong wind blows.
MAIN FEATURES

DEDICATED CASING

Porto casing possesses 3 finishing options to fit different interior design styles. Daze and Laurent and Kreta by Cosentino fit best in rich and luxurious surroundings. Porto with Kreta casing will be a focal point for gardens, patios and hotels in a modern and minimalistic style. What’s more, the casing is made of materials that can withstand various weather conditions, such as rain or snow.

EASIEST CONTROL OF THE FLAME

Adjust the flame of the BEV fireplace from the distance. Porto is controlled with an included remote control, a dedicated FLA4 NET ZERO app or with an integrated control panel.

ADJUSTABLE FLAME HEIGHT

Porto allows you to choose from 6 flame height levels accordingly to your needs. The lower fire levels allow to extend the operating time up to 14 hours. Higher fire levels give significant heating power and raise the heat in the room and surroundings faster.

INTEGRATED CASTOR WHEELS

The castors in a bottom compartment allow quick and effortless relocation whenever you need it.

FAQ

How to replace the empty fuel container?

Unscrew the cap with the pumping hose and remove the empty container from the holder. Insert a full fuel container, ensuring the cap is removed beforehand, and carefully place it into the holder. Once the new container is in position, screw the cap with the pumping hose back on securely to ensure a proper seal, and check for any leaks before operating the system.

Where the fuel container is located?

It is located in the storage compartment below the firebox.

Are the BEV products Eco-friendly?

Thanks to the complete combustion process, fireplaces with BEV (beurning Ethanol Vapours) technology do not release
any harmful substances into the environment.

Does a BEV fireplace produce heat?

Yes, the BEV fireplaces generating a real fire that produce heat.

Why there must be a 1/H air exchange?

This is a standard construction requirement for any habitable space. As the length of the fireplace increases, so does the amount of re-circulated air, which means a larger air volume is needed. This ensures that the recirculated air does not lower the overall air quality in the room within an hour. This is the minimum air exchange requirement. Increasing the air
exchange rate will further enhance air quality by reducing the concentration of recirculated air.

Is it possible to replace the remote control?

Yes, the remote control can be ordered through the service help form ( https://planikafires.com/service-help/ ). After the
new remote is received, the service team must be contacted again by filling the form, they must remotely pair the remote with the fireplace.

What are the by-products produced during bioethanol burning process?

In Planika’s BEV (Burning Ethanol Vapors) fireplaces, the bioethanol burning process is carefully designed to maximize efficiency and minimize harmful emissions. The BEV technology specifically burns ethanol vapors rather than liquid ethanol, leading to a more complete combustion process. The by-products are Carbon Dioxide (CO₂) and Water Vapor
(H₂O). This CO₂ emission is comparable to what humans exhale and is minimal in well-ventilated rooms.

Are the BEV products safe to use?

Planika’s BEV technology is designed to provide a safe, clean, and environmentally friendly fire experience by burning
ethanol vapors rather than liquid ethanol directly.Here are some aspects of their safety features:1. No Direct Contact with Flame: Planika’s BEV technology creates flames from burning ethanol vapors, which eliminates the risk of spillage and uncontrolled burning of liquid ethanol, making it safer than traditional ethanol fireplaces.2. Automated Control Systems: These fireplaces often include electronic control systems, which manage the ignition, flame height, and shutdown process. This automation minimizes user interaction with the flame and enhances safety.3. Sensors and Safety Features:CO₂ and Temperature Sensors: Many Planika fireplaces are equipped with sensors that monitor the carbon dioxide level and temperature. If the CO₂ level exceeds a safe limit or if there’s an unusual temperature spike, the system shuts down automatically.Tilt and levelling sensor- a safety features designed to shut off the fireplace if it is tilted beyond a safe angle. This prevents accidental fuel spills or fires if the unit is knocked over or destabilized.Spill-Proof Design: BEV fireplaces are typically designed to prevent ethanol leaks, reducing the risk of accidental fires dueto fuel spills.

Is the chimney or flue required for the BEV fireplaces?

There is no chimney or flue required for the BEV (Burning Ethanol Vapour) technology fireplaces. Thanks to the BEV technology products are producing minimal carbon dioxide and water vapor without smoke or harmful fumes.

Can’t open the fuel cap.

Remove the ring under the cap.

Can I connect the fireplace to the UPS battery?

There is no technical contraindications to use UPS baterry. Although, the output must be 230 V and the battery must operate on a Pure sinus wave. The capacity of the UPS battery will determine how long it can power the device in the event of a power failure.

Where are Planika fireplaces manufactured?

Planika fireplaces are manufactured in Poland, EU

Are the glass panels getting hot?

Yes, the glass screens may get hot (up to 100 degrees Celsius).

Can I use it around children?

Parts such as glass panels may become very hot and it is advisable to keep it away from children.

Why can’t I use ceramic logs in all fireplaces ?

Our logs are too large for some models and could cause a malfunction of the device

Is the fireplace under warranty?

The manufacturer gives 2 years warranty from the date of purchase.

Can I put any decorative elements like ceramic logs around the fire?

Yes, you can use decorations such as logos, but not in all models. Whether such accessories can be used for a given product is specified in its user manual. It is only allowed to use accessories indicated by the manufacturer and tested by us. Others may damage the device

Cleaning recommendations

Use clean damp cloth with a solution of water and light detergent.

Where to order the Bioethanol fuel?

Approved bioethanol fuel is distributed by Planika: Online Store , Amazon, Dealers Map

How to order spare parts ?

The most popular spare parts can be found in our Online Store . However, if you need a part that you can’t find there, contact our Service

Where to report issues with the product?

To report a technical issue, please fill out online Service Form Our technical serviceteam will contact you shortly to diagnose and fix the issue.

Where to find a local dealer?

Please visit our Dealers Map

Where to find the heat output to particular models?

The heat output for a specific models can be found on the technical cards. The technical cards are available for a
download in the Files Library

Where to find manuals and technical cards?

To download manual and technical cards please visit our Files Library

Where to find 3d or CAD files?

To download files please visit our Files Library
